Do You Know the Working Principle of Relay Automatic Assembly Equipment?

1. Principle and application of relay

Relay is an electrical control device with high stability and reliability. It converts electrical information through electrical signal control switch. In various electrical control automation systems, relays play an important role. Due to the diverse use of relays and their wide range of uses, the manufacture and installation of various types of relays require the use of efficient automated assembly processes.

2. Working principle of Relay Automatic Assembly Equipment

Relay Automatic Assembly Equipment is a highly efficient automated assembly machine that can realize the automated assembly of relays. It mainly consists of three parts: automatic feeding system, automatic distribution system and automatic assembly system.

Automatic feeding system: semi-automatic equipment suitable for automatic feeding, which uses a programmable multi-axis controller to control the linear motor for material distribution operation, so that the components are stably transferred to the automatic distribution system.

Automatic distribution system: a system suitable for automated classification and distribution of multiple types of components, which uses advanced conveyor belts, vibrating plate distributors, conveyor belt vibrators and photoelectric detection technologies, so that components can accurately enter the automatic assembly system according to the required models and quantities.

Automatic assembly system: suitable for automatic assembly, debugging and testing of relays. It is the core part of the whole machine. It adopts advanced motor controller, image recognition system and other technologies, which can quickly and efficiently complete the automatic assembly of relays.

III. Key steps of Relay Automatic Assembly Equipment

Relay Automatic Assembly Equipment classifies various types of components and loads them into the automatic distribution system. The components are sent to the automatic distribution system through the automatic feeding system. In the automatic distribution system, the components are accurately classified and sent to the automatic assembly system according to the specified quantity and model. The automatic assembly system assembles, debugs and tests the components according to the input instructions. After the assembly is completed, the relay is inspected and tested, and the relays that meet the requirements are manually sorted and processed later.

Relay Automatic Assembly Equipment is a high-efficiency and high-precision automatic assembly machine with broad application prospects in the electronic manufacturing industry. This article analyzes its working principle and key steps, which gives people a deeper understanding of the technologies and methods used in the automatic production process of relays.
